Flanges are basically internal or external ridge sometimes called as rim (lip) for providing strength. It is used for attachment or joining of other objects such as pipe end, steam cylinder. Therefore, we can say that flanges are in form of a wheel. You can find many different Alloy Steel F12 Flanges specifications and standards worldwide that are offered by the max steels. In order to impose easy interchangeability and functionality, we design it in standardized dimensions such as length, width, thickness, outer diameter as well as internal diameter. If you wish to buy local standards then you can easily make a purchasing as we align the product with the ISO standard.
We divide many of the steel flanges into pressure classes, thus allowing them to become capable of arranging into pressure ratings. We offer steel F12 flanges based on pressure classes for different temperature and pressure applications. Processing plants as well as generating station can make use of unique pressure classes. The flanges faces can be easily molded into standardized dimensions and offer obscure types with possible rates.
The initial price of the theoretical and compact flange is low but the performance is higher. Our regularly offered alloy steel F12 flanges with close tolerance level and sophisticated design. The installation requirement is low. Compact flanges can be easily utilized all over the world. It is best for cold and cryogenic work because of the high-temperature operation.
The testing of the chrome molybdenum alloy steel F12 flanges includes IGC test, PMI test, hardness test, corrosion resistance test, flaring test, etc. After testing, the packaging is done with wooden cases and wooden boxes.
| STANDARD | UNS | WERKSTOFF NR. |
| Alloy Steel F12 | K11562 / K11564 | - |
Specifications : ASTM A182 / ASME SA182
Dimensions : ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Standard : ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Size : 1/2" (15 NB) to 48" (1200NB)
Class/Pressure : 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
Flange Face Type : Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
Form : Slip on flanges, Socket weld flanges, Forged flanges, Blind flanges, Welding neck flange, Ring type joint flange, Spectacle blind flange, Reducing flange, Threaded / Screwed flange, Tongue and Groove flange, Long weld neck flange, Plate flange, Flate Face flanges, ASME B16.5 flanges.
ASTM A182 / SA182M - This specification covers forged low alloy and steel piping components for use in pressure systems.
ANSI B16.5 - standard covers alloy Pipe Flanges and Flanged Fittings from NPS 1/2 through NPS 24 Metric/Inch in pressure class 150 to class 2500.
ANSI/ASME B16.47 - Term B16.47 or B 16 47 or ANSI B 16 47 are all used interchangeabily and refers to the same standard. ASME B16.47(Large Diameter Steel Flanges) is a standard for large diameter steel pipe flanges sized from NPS 26 through NPS 60.
ANSI B16.48 - Standard covers pressure–temperature ratings, materials, dimensions, tolerances, marking, and testing for operating line blanks in sizes NPS 1⁄2 through NPS 24 for installation between ASME B16.5 flanges in the 150, 300, 600, 900, 1500, and 2500 pressure classes.
| Grade | C | Mn | P | S | Si | Ni | Ch | Mo | Cb |
| F12 | 0.05-0.15 | 0.30-0.60 | 0.045 | 0.045 | 0.50 max | - | 0.80-1.25 | 0.44-0.65 | - |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| F12 | 415 | 220 | 20 | - | 121-174 |
Corrosion resistant
Durable functioning
Malleable
Heat resistance
High strength
Excellent conductivity
Impeccable finish
Enhanced service life
Precisely designed
